Casa / Productos / Caja de cambios oscilante / PC200-6 Reducción de swing 20y-26-00150 20y-26-00151 20Y2600150 20Y2600151 Swing Machinery Assy PC200-6 Swing Gearbox

PC200-6 Reducción de swing 20y-26-00150 20y-26-00151 20Y2600150 20Y2600151 Swing Machinery Assy PC200-6 Swing Gearbox

Compartir con:

PC200-6 Reducción de swing 20y-26-00150 20y-26-00151 20Y2600150 20Y2600151 Swing Machinery Assy PC200-6 Swing Gearbox

Estado de Disponibilidad:

Cantidad:



Preguntar Añadir al carrito

Descripción del Producto

PARAMETROS DEL PRODUCTO

Pnombre de arte	PC200-6 Swing Gearbox
Equipo	Aplicar a la excavadora de Komatsu
Parte no.	20y-26-00150 20y-26-00151
No.1 dientes de spline de engranaje solar	19 splines
Dientes del eje del piñón oscilante	15 T
Condición del artículo	Nuevo
Logo	Lb
Peso bruto	17 kg
Moq	1 PC

Descripción del Producto

Piezas en el grupo:

Pos.	Parte no	Cantidad	Nombre de piezas	Comentario
	20y-26-00151	[1]	Swing Machinery A. Komatsu	190 kg.
			["Sn: 102083-UP "] Análogos: ["20y2600150 "] \| 1.
	20y-26-00150	[1]	Swing Machinery A. Komatsu	190 kg.
			["SN: 96514-102082 "] Análogos: ["20y2600151 "] \| 1.
1.	20y-26-22210	[1]	CASO Komatsu	76 kg.
			["SN: 96514-UP "]
2.	20y-26-22330	[1]	COJINETE Komatsu China	3.28 kg.
			["SN: 96514-UP "] Análogos: ["20y2622331 ", "20y2622430 "]
3.	20y-26-22340	[1]	COJINETE Komatsu China	9.6 kg.
			["SN: 96514-UP "] Análogos: ["20y2622342 ", "20y2622440 "]
4.	20y-26-22191	[1]	CUBRIR Komatsu	4.6 kg.
			["SN: 97767-UP "] Análogos: ["20y2622190 "]
	20y-26-22190	[1]	CUBRIR Komatsu	4.6 kg.
			["Sn: 96514-97766 "] Análogos: ["20y2622191 "] \| 4.
5.	01010-81045	[12]	TORNILLO Komatsu	0.039 kg.
			["SN: 96514-UP "] Análogos: ["0101051045 ", "01010d1045 "]
6.	01643-31032	[12]	LAVADORA Komatsu	0.054 kg.
			["SN: 80001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032 ", "6127212530 ", "802170002 ", "R0164331032 "]
7.	20y-26-22420	[1]	SELLO Komatsu China	0.3 kg.
			["Sn: 97767-UP "]
	07012-00125	[1]	SELLO Komatsu China	0.142 kg.
			["Sn: 80001-97766 "] \| 7.
		[-1]	. (20y-26-22420 {20y-26-22191)}
			\| $$ 12.
8.	20y-26-21141	[1]	Eje¤ 15 dientes Komatsu OEM	35 kg.
			["SN: 96514-UP "] Análogos: ["20y2621140 ", "20y2621142 "]
9.	20y-26-22170	[1]	TRANSPORTADOR Komatsu	8.55 kg.
			["SN: 96514-UP "]
10.	20y-26-22141	[4]	Engranajeund 36 dientes Komatsu China	1.8 kg.
			["SN: 97709-UP "] Análogos: ["20y2622140 "]
	20y-26-22140	[4]	Engranajeund 36 dientes Komatsu China	1.8 kg.
			["SN: 96514-97708 "] Análogos: ["20y2622141 "] \| 10.
11.	20G-26-11240	[4]	COJINETE Komatsu China	0.24 kg.
			["SN: 96514-UP "] Análogos: ["20G2611241 ", "20G2611410 "]
12.	20y-27-21240	[8]	LAVADORA Komatsu China	0.02 kg.
			["SN: 96514-UP "]
13.	20y-26-22250	[4]	ALFILER Komatsu China	0.52 kg.
			["SN: 96514-UP "]
14.	20y-27-21280	[4]	ALFILER Komatsu China	0.01 kg.
			["SN: 96514-UP "]
15.	20y-26-21240	[1]	LÁMINA Komatsu	5.1 kg.
			["Sn: 80001-up "]
dieciséis.	112-32-11211	[1]	Zapato de perno Komatsu	0.09 kg.
			["Sn: 80001-up "]
17.	20y-26-22151	[1]	Engranajeund 101 dientes Komatsu	18.8 kg.
			["SN: 102083-UP "] Análogos: ["20y2622150 "]
	20y-26-22150	[1]	Engranajeund 101 dientes Komatsu	18.8 kg.
			["SN: 96514-102082 "] Análogos: ["20y2622151 "] \| 17.
18.	20y-26-22131	[1]	Gear¤ 27 dientes Komatsu	2.15 kg.
			["SN: 97709-UP "] Análogos: ["20y2622130 "]
	20y-22-22130	[1]	Gear¤ 27 dientes Komatsu	2.15 kg.
			["SN: 96514-97708 "] Análogos: ["20y2622131 "] \| 18.
19.	04064-07525	[1]	RING Komatsu	0.026 kg.
			["SN: 96514-UP "]
20.	20y-26-22220	[1]	Arandela de empuje Komatsu	0.04 kg.
			["SN: 96514-UP "]
21.	20y-26-22160	[1]	TRANSPORTADOR Komatsu	5.1 kg.
			["SN: 96514-UP "]
22.	20y-22-22120	[3]	Engranajeund 39 dientes Komatsu China	1.25 kg.
			["SN: 96514-UP "]
23.	20y-26-21281	[3]	COJINETE Komatsu	0.1 kg.
			["Sn: 110071-UP "] Análogos: ["20y2621280 ", "20x2621240 ", "20y2621510 "]
	20y-26-21280	[3]	COJINETE Komatsu	0.1 kg.
			["Sn: 80001-110070 "] Análogos: ["20y2621281 ", "20x2621240 ", "20y2621510 "] \| 23.
25.	20y-26-22240	[3]	ALFILER Komatsu	0.367 kg.
			["SN: 96514-UP "]
27.	20y-26-22110	[1]	Gear¤ 22 dientes Komatsu	0.4 kg.
			["SN: 96514-UP "]
28.	20y-26-22230	[1]	Arandela de empuje Komatsu	0.1 kg.
			["SN: 96514-UP "]
29.	20y-26-22410	[1]	CUBRIR Komatsu China
			["SN: 96514-UP "]
30.	01011-81450	[4]	TORNILLO Komatsu China
			["SN: 96514-UP "]
31.	01643-31445	[4]	LAVADORA Komatsu	0.019 kg.
			["SN: 96514-UP "] Análogos: ["0164301432 "]
32.	07042-30617	[1]	ENCHUFAR Komatsu China
			["SN: 96514-UP "]
33.	07042-30108	[1]	ENCHUFAR Komatsu	0.008 kg.
			["SN: 96514-UP "] Análogos: ["0704220108 "]
34.	07042-30415	[1]	ENCHUFAR Komatsu	0.056 kg.
			["SN: 96514-UP "]
